Key Features:

The Performance Liner® Lateral System is a unique cured in-place process that allows the installer the freedom to position the liner anywhere in the pipe by inverting through a cleanout. The liner can be directed either upstream or downstream using LMK’s patented guide shoe. In addition, this versatile system is capable of being installed in pipes under foundations, inside walls or in vertical applications. LMK’s Lateral system is truly a no dig situation for renewing lateral pipes since the entire process can be completed through a cleanout. Gasket sealing O-rings are placed at the upstream and downstream ends of the liner providing a verifiable, non-leaking lateral liner that is compatible with all types of piping.

LMK’s lateral liners also include compressible material at the upstream end of the liner, producing a smooth tapered transition to the old pipe. This process renews laterals from 4-8 inches in diameter in continuous lengths up to 130 feet. Inversion tanks come in two sizes (36 inch or 18 inch) and are equipped with a camera port so the liner can be visually inspected under pressure for proper placement prior to the liner being cured.

ASTM F1216

Standard practice for rehabilitation of existing pipelines and conduits by the inversion and curing of a resin-impregnated tube.

Significance and Use

Purchase the full version of this standard by visiting the ASTM website here.

This practice is for use by designers and specifiers, regulatory agencies, owners, and inspection organizations who are involved in the rehabilitation of conduits through the use of a resin-impregnated tube inverted through the existing conduit. As for any practice, modifications may be required for specific job conditions.

1. Scope

  1. This practice describes the procedures for the reconstruction of pipelines and conduits (4 to 108-in. diameter) by the installation of a resin-impregnated, flexible tube which is inverted into the existing conduit by use of a hydrostatic head or air pressure. The resin is cured by circulating hot water or introducing controlled steam within the tube. When cured, the finished pipe will be continuous and tight-fitting. This reconstruction process can be used in a variety of gravity and pressure applications such as sanitary sewers, storm sewers, process piping, electrical conduits, and ventilation systems.
