  The LMT™ (Lined Main Tap) Saddle Installation System is engineered to connect a lateral sewer service pipe to a liner inside a rehabilitated mainline. The LMK Saddle Installation System is designed to connect a lateral sewer service pipe directly to a mainline pipe.
  • The saddle is sized to surround the liner or pipe beyond the spring line, which creates a clamping effect that draws the saddle firmly on to the liner or the pipe.
  • The universal LMK Adhesive bonds the saddle to the liner or host pipe, providing a flexible non-leaking main-to-lateral connection. A special two-part adhesive is available for HDPE liners/pipes.
  • The saddle is compatible with CIPP and fold and form liners.
  • The saddle is also compatible with a variety of pipes including cast iron, clay, concrete, PVC and HDPE.
  • A variety of saddle sizes are available - for pipes ranging from 6-24 inches.
  • Many saddle sizes are stocked but not all; contact LMK customer service for availability.
